| 型号 | DSOX6002A | DSOX6004A | MSOX6002A | MSOX6004A | |||||
| Input channels | 2 | 4 | 2 + 16 | 4 + 16 | |||||
| Choose your bandwidth | |||||||||
| Bandwidth options | 1 GHz | 2.5 GHz | 4 GHz | 6 GHz | |||||
| - | For 2 channel models | Default | DSOX6002A-02G | DSOX6002A-04G | DSOX6002A-06G | ||||
| - | For 4 channel models | Default | DSOX6004A-02G | DSOX6004A-04G | DSOX6004A-06G | ||||
| Calculated rise time (10 to 90%) | ≤ 350 ps | ≤ 140 ps | ≤ 112.5 ps | ≤ 75 ps | |||||
| Maximum sample rate | 20 GSa/s half channels, 10 GSa/s full channels | ||||||||
| Maximum memory depth | 4 Mpts half channels, 2 Mpts all channels | ||||||||
| Display size and type | 12.1-inch capacitive multi-touch/gesture-enabled display | ||||||||
| Waveform update rate | ture-enabled display Waveform update rate > | ||||||||
| Typical noise floor at 1 mV/div, 50 Ω | 115 μVrms | 150 μVrms | 150 μVrms | 210 μVrms | |||||
| Vertical system analog channels | |||||||||
| Hardware bandwidth limits | 1 MΩ | 20 MHz, 200 MHz (selectable per channel) | |||||||
| - | 50 Ω | 20 MHz, 200 MHz, 1.5 GHz, 3 GHz (selectable per channel) | |||||||
| Input coupling | AC, DC | ||||||||
| Input impedance | Selectable: 1 MΩ ± 1% (14 pF), 50 Ω ± 3% | ||||||||
| Input sensitivity range | 1 MΩ | 1 mV/div to 5 V/div 2 (200 MHz bandwidth limit at ≤ 2 mV/div) | |||||||
| 50 Ω | 1 mV/div to 1 V/div | ||||||||
| Vertical resolution | 8 bits (measurement resolution is 12 bits with averaging) | ||||||||
| DC vertical gain accuracy | ± 3 div: 1.5% of full scale (typical) | ||||||||
| - | ± 4 div: 2.5% of full scale (warranted) | ||||||||
| DC vertical offset accuracy | ± 0.1 div ± 2 mV ± 1% of offset setting (valid for an offset of ≤ ± 12 divisions) | ||||||||
| Horizontal system analog channels 1 | |||||||||
| Time base range | 500 ps/div to 50 s/div | 100 ps/div to 50 s/div | 100 ps/div to 50 s/div | 100 ps/div to 50 s/div | |||||
| Time base accuracy | ± 1.6 ppm + aging factor (1 year: ± 0.5 ppm, 2 years: ± 0.7 ppm, 5 years: ± 1.5 ppm, 10 years: ± 2.0 ppm) | ||||||||
| Time base resolution | 2.5 ps | ||||||||
| Channel-to-channel deskew range | ± 100 ns | ||||||||
| Modes | Main, zoom, roll, XY | ||||||||
| Maximum analog channels sample rate | 20 GSa/s half channel interleaved, 10 GSa/s all channel | ||||||||
| Analog channels equivalent sample rate | Not available | 400 GSa/s | |||||||
| Maximum analog channels record length | ≤ 2 GSa/s | 4 Mpts half channel interleaved, 2 Mpts all channel | |||||||
| - | > 2 GSa/s | 1 Mpts half channel interleaved, 500 kpts all channe | |||||||
| Maximum digital channels sample rate | 2 GSa/s half pods interleaved, 1 GSa/s all pods | ||||||||
| Maximum digital channels record length | 4 Mpts half pods interleaved, 2 Mpts all pods |
1 GHz - 6 GHz 带宽可升级型号仅有 6 英寸（15 厘米）深、15 磅（6.8 千克）重
12.1 英寸电容触摸屏，支持多点触控和 InfiniiScan 区域触摸触发
本底噪声和波形更新速率
标配直方图和色度功能，以及增强彩色 FFT
抖动和实时眼图分析（可选）
六位一体的综合仪器，全部功能特性均可升级。标配示波器和 16 个数字通道，可选配串行协议触发和解码、双通道函数/任意波形发生器、3 位数字电压表、10 位频率计数器和累加器
包括 14 国语言版本的语音控制
